Product Description
| Size | 05 | 08 | 15 | 30 | 40 | 80 | 150 |
| Motor frame size | 71 | 80 | 90 | 100 | 112 | 132 | 160 |
| Rated torque(N.M) | 5 | 7.5 | 15 | 30 | 40 | 80 | 150 |
| Rated power 20ºC(W) | 28 | 30 | 45 | 60 | 65 | 90 | 110 |
| Connection time T1(ms) | 63 | 87 | 110 | 140 | 152 | 165 | 214 |
| Disconnection time T2(ms) | 55 | 72 | 95 | 120 | 130 | 140 | 180 |
| Normal clearance δ(mm) | 0.3 | 0.3 | 0.4 | 0.4 | 0.5 | 0.5 | 0.6 |
| Max.clearance δmax (mm) | 0.8 | 0.8 | 1.0 | 1.0 | 1 | 1.0 | 1.2 |
| Rated voltage DC(V) | 96 | 170 | |||||
| Allowed speed n(rpm) | 3000 | ||||||
Specifications:
Braking torques: 05-150Nm;
10 sizes, keep interchangeability with national standard motor size ;
Common voltages: 24,96,180,205VDC, other voltages on request;
Temperature class F (155°C), heat resistance of rotor up to 200ºC;
Compact design, modular design, easy disassembly and replacement;
Preset brake gap, adjustable air gap;
Single and double brake structures with a mute device can be selected.;
Hand release available as an option;
High quality spring material, long service life, reasonable design, never invalid;
Applications:
Lift, escalator
Brake motors
Port machinery
Cranes
Conveyors
Hoisting equipment
Metallurgical machinery
Material handling equipment
Light industrial packaging
Controlled drives
Automation technology
Textile and printing
Forklift truck
Wood working machines
